Raccords à bride ISO 6164 & Cetop
Raccords à bride ISO 6164 & Cetop
Vous trouverez ici exactement ce qu’il faut à votre entreprise. Notre large gamme de produits, comprenant plus de 8000 pièces différentes, offre des solutions sur mesure à votre projet. Notre portefeuille de produits propose des brides SAE (ISO 6162), des brides monobloc, à visser, avec filetage extérieur, des brides à souder à l’intérieur et l’extérieur, toutes SAE, ainsi que des brides avec collets à souder. Tous ces produits sont disponibles en version droite ou dotés d’un angle de 90°.
De plus, vous obtenez chez nous des brides de fermeture, des brides intermédiaires, des brides avec raccord pour mesure, des connecteurs en T, des brides de réduction, des brides à collerette et des blocs SAE. Sans oublier les raccords pour pompe à engrenage et les raccords à bride carrée (ISO 6164) droits et dotés d’un angle de 90° et Cetop (standard).
Faites-vous vous-même une idée de notre très importante gamme de produits en cliquant ci-dessous sur notre catalogue en ligne.
Raccords à bride ISO 6164

Square flange
Katalogseite: 111

Bestellbezeichnung: |
||
Square flange |
VK-… |
VK-X-… |

Butt weld centering flange – ND 160 – ISO 6164
Katalogseite: 112

Bestellbezeichnung: |
C45 |
|
butt weld flange |
VKA 32-.../AxSM |
|
butt weld flange-coupling |
VKK 28-.../AxSM |

Butt weld centering flange – ND 250 – ISO 6164
Katalogseite: 113

Bestellbezeichnung: |
C45 |
|
butt weld flange |
VKA 33-.../AxSM |
|
butt weld flange-coupling |
VKK 29-.../AxSM |

Butt weld centering flange – ND 315 – ISO 6164
Katalogseite: 114

Bestellbezeichnung: |
C45 |
|
butt weld flange |
VKA 34-.../AxSM |
|
butt weld flange-coupling |
VKK 30-.../AxSM |

Butt weld centering flange – ND 400 – ISO 6164
Katalogseite: 115

Bestellbezeichnung: |
C45 |
|
butt weld flange |
VKA 43-.../AxSM |
|
butt weld flange-coupling |
VKK 41-.../AxSM |

Centering flange plug – ND 160 – ISO 6164
Katalogseite: 116

Bestellbezeichnung: |
||
flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts) |
VKB-... -160KM |
|
flange plug without o-ring groove (flange plug including square or round flange respectively) |
G-VKB-... -160K |

Centering flange plug – ND 250 ND 315 – ISO 6164
Katalogseite: 117

Bestellbezeichnung: |
||
flange plug with o-ring groove only |
VKB-...250 |
|
flange plug without o-ring groove only |
G-VKB-... |
|
flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts) |
VKB-... KM |
|
flange plug without o-ring groove (flange plug including square or round flange respectively) |
G-VKB-... K |

Centering flange plug – ND 400 – ISO 6164
Katalogseite: 118

Bestellbezeichnung: |
||
flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts) |
VKB-... -400KM |
|
flange plug without o-ring groove (flange plug including square or round flange respectively) |
G-VKB-... -400K |

90° butt weld centering flange – ISO 6164
Katalogseite: 119

Bestellbezeichnung: |
C15 |
|
elbow only |
VKW-... |
|
including bolts and o-ring |
VKW-...M |

T-flange connector
Katalogseite: 120

Bestellbezeichnung: |
316L |
|
T-flange connector only |
VKV-... |
VKV-X-... |
including flange, bolts and o-ring |
VKV-...KM |
VKV-X-...KMX |
Raccords à bride CETOP

CETOP-butt weld flange
Katalogseite: 121

Bestellbezeichnung: |
||
butt weld flange (including metric bolts and o-ring) |
CET-...M |

CETOP-butt weld flange-coupling
Katalogseite: 122

Bestellbezeichnung: |
||
flange-coupling (including metric bolts and o-ring) |
D-CET-...M |

CETOP-flange plug
Katalogseite: 123

Bestellbezeichnung: |
||
flange plug (including metric bolts and o-ring) |
BS-...M |

CETOP 90° butt weld flange
Katalogseite: 124

Bestellbezeichnung: |
||
flange only |
CET-.../90... |
|
including metric bolts and o-ring |
CET-.../90...M |
