ISO 6164 y conexiones de brida Cetop
ISO 6164 y conexiones de brida Cetop
Aquí encontrará lo correcto para su empresa. Nuestra amplia gama de productos de más de 8,000 piezas diferentes permite soluciones a medida para su proyecto. Nuestra cartera de productos incluye bridas SAE (ISO 6162), bridas SAE completas, soldadura y bridas o collares de soldadura. Todos estos productos están disponibles en forma recta y 90 °.
Además, recibirá bridas de cierre, bridas intermedias, bridas con conexión de medición, conectores en T, bridas reductoras, bridas y bloques SAE. Además de conexiones para bombas de engranajes y conexiones de brida cuadrada (ISO 6164) en forma recta y 90 ° y Cetop (estándar).
Obtenga una idea de nuestra amplia gama de productos haciendo clic en nuestro catálogo en línea a continuación.
Conexiones de brida ISO 6164

Square flange
Katalogseite: 111

Bestellbezeichnung: |
||
Square flange |
VK-… |
VK-X-… |

Butt weld centering flange – ND 160 – ISO 6164
Katalogseite: 112

Bestellbezeichnung: |
C45 |
|
butt weld flange |
VKA 32-.../AxSM |
|
butt weld flange-coupling |
VKK 28-.../AxSM |

Butt weld centering flange – ND 250 – ISO 6164
Katalogseite: 113

Bestellbezeichnung: |
C45 |
|
butt weld flange |
VKA 33-.../AxSM |
|
butt weld flange-coupling |
VKK 29-.../AxSM |

Butt weld centering flange – ND 315 – ISO 6164
Katalogseite: 114

Bestellbezeichnung: |
C45 |
|
butt weld flange |
VKA 34-.../AxSM |
|
butt weld flange-coupling |
VKK 30-.../AxSM |

Butt weld centering flange – ND 400 – ISO 6164
Katalogseite: 115

Bestellbezeichnung: |
C45 |
|
butt weld flange |
VKA 43-.../AxSM |
|
butt weld flange-coupling |
VKK 41-.../AxSM |

Centering flange plug – ND 160 – ISO 6164
Katalogseite: 116

Bestellbezeichnung: |
||
flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts) |
VKB-... -160KM |
|
flange plug without o-ring groove (flange plug including square or round flange respectively) |
G-VKB-... -160K |

Centering flange plug – ND 250 ND 315 – ISO 6164
Katalogseite: 117

Bestellbezeichnung: |
||
flange plug with o-ring groove only |
VKB-...250 |
|
flange plug without o-ring groove only |
G-VKB-... |
|
flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts) |
VKB-... KM |
|
flange plug without o-ring groove (flange plug including square or round flange respectively) |
G-VKB-... K |

Centering flange plug – ND 400 – ISO 6164
Katalogseite: 118

Bestellbezeichnung: |
||
flange plug with o-ring groove (flange plug including square or round flange respectively, o-ring and bolts) |
VKB-... -400KM |
|
flange plug without o-ring groove (flange plug including square or round flange respectively) |
G-VKB-... -400K |

90° butt weld centering flange – ISO 6164
Katalogseite: 119

Bestellbezeichnung: |
C15 |
|
elbow only |
VKW-... |
|
including bolts and o-ring |
VKW-...M |

T-flange connector
Katalogseite: 120

Bestellbezeichnung: |
316L |
|
T-flange connector only |
VKV-... |
VKV-X-... |
including flange, bolts and o-ring |
VKV-...KM |
VKV-X-...KMX |
Conexiones de brida CETOP

CETOP-butt weld flange
Katalogseite: 121

Bestellbezeichnung: |
||
butt weld flange (including metric bolts and o-ring) |
CET-...M |

CETOP-butt weld flange-coupling
Katalogseite: 122

Bestellbezeichnung: |
||
flange-coupling (including metric bolts and o-ring) |
D-CET-...M |

CETOP-flange plug
Katalogseite: 123

Bestellbezeichnung: |
||
flange plug (including metric bolts and o-ring) |
BS-...M |

CETOP 90° butt weld flange
Katalogseite: 124

Bestellbezeichnung: |
||
flange only |
CET-.../90... |
|
including metric bolts and o-ring |
CET-.../90...M |
