Find the right product for your company. Our wide range of products consisting of over 8000 individual parts makes it possible to create customised solutions for your company. Our product portfolio includes SAE flanges (ISO 6162), SAE full flanges, screw-in flanges, external thread flanges, weld-in and weld-on flanges as well as flanges with butt-welded collars. These products can all be delivered in straight and 90° versions.

Furthermore we can deliver closing flanges, connecting flanges, flanges with measurement connections, T-connectors, reducing flanges, raised-edge flanges and SAE blocks. These as well as connections for gear pumps and square-head flange connections (ISO 6164) are available as straight and 90° versions and Cetop (standard) versions.

Get a better picture of our range of products by clicking through our extensive online catalogue below.


SAE-flange adapter metric 24° DIN 3901

Catalogue page: 60,61

Data Sheet Product Enquiry

Ordering code:

C22

316L

adaptor only

SFCE-…

SFCE-X-…

including split flanges, metric bolts and o-ring (nut and cutting ring)

SFCE-…M(M)

SFCE-X-…MX(M)

including split flanges, UNC bolts and o-ring (nut and cutting ring)

SFCE-…U(M)

SFCE-X-…UX(M)

SAE-flange metric tapped 24° DIN 3901

Catalogue page: 62,63

Data Sheet Product Enquiry

Ordering code:

flange only

AFG-…

including metric bolts and o-ring

AFG-…M

including UNC bolts and o-ring

AFG-…U

including bolts (metr. or UNC), o-ring, cutting ring and nut

AFG-…MM (UM)

SAE-flange metric tapped 24° companion DIN 3901

Catalogue page: 64,65

Data Sheet Product Enquiry

Ordering code:

316L

flange with metric threads

GFG-…L/S…

SAE-90° flange adapter 24° DIN 3901 – forged

Catalogue page: 66,67

Data Sheet Product Enquiry

Ordering code:

316L

only 90° elbow

WFG-…

WFG-X-…

including split flanges, bolts and o-ring

WFG-…M

WFG-X-…MX

including split flanges, bolts, o-ring, cutting ring and nut

WFG-…MM

WFG-X-…MMX

SAE-90° flange adapter 24° DIN 3901 – brazed

Catalogue page: 68

Data Sheet Product Enquiry

Ordering code:

ST37*1

adapter only

SFCE-…

including split flanges, metric bolts and o-ring (nut and cutting ring)

SFCE-…M(M)

including split flanges, UNC bolts and o-ring (nut and cutting ring)

SFCE-…U(M)

SAE-90° threaded flange 24° DIN 3901

Catalogue page: 69

Data Sheet Product Enquiry

Ordering code:

flange only

AFG-…/90M…

including metric bolts and o-ring

AFG-…/90M…M

including UNC bolts and o-ring

AFG-…/90M…U

SAE-45° flange-adapter DIN 3901

Catalogue page: 70

Data Sheet Product Enquiry

Ordering code:

only 45° flange-adapter

WFG-…-45-…

WFG-X-…-45-…

including split flanges, bolts and o-ring

WFG-…-45-…M

WFG-X-…-45-…MX

including split flanges, bolts, o-ring, cutting ring and nut

WFG-…-45-…MM

WFG-X-…-45-…MMX

SAE-adapter JIC 37°

Catalogue page: 71

Data Sheet Product Enquiry

Ordering code:

C22

316L

adaptor only

SFCE-…J

SFCE-X-…J

including split flanges, metric bolts and o-ring

SFCE-…JM

SFCE-X-…J...MX

including split flanges, UNC bolts and o-ring

SFCE-…JU

SFCE-X-…J...UX

SAE-threaded flange JIC 37°

Catalogue page: 72,73

Data Sheet Product Enquiry

Ordering code:

flange only

AFG-…

including metric bolts and o-ring

AFG-…M

incl. UNC-Schraubensatz und O-Ring

including UNC bolts and o-ring

AFG-…U

SAE-90° flange adapter JIC 37° – forged

Catalogue page: 74,75

Data Sheet Product Enquiry

Ordering code:

316L

only 90° elbow

WFG-…

WFG-X-…

including split flanges, metric bolts and o-ring

WFG-…M

WFG-X-…MX

including split flanges, UNC bolts and o-ring

WFG-…U

WFG-X-…UX

SAE-45° flange adapter JIC 37° – forged

Catalogue page: 76

Data Sheet Product Enquiry

Ordering code:

only 45° flange-adapter

WFG-…-45-J…

WFG-X-…-45-J…

including split flanges, bolts and o-ring

WFG-…-45-J...M

WFG-X-…-45-J…MX

SAE-flange adapter BSPP thread

Catalogue page: 77

Data Sheet Product Enquiry

Ordering code:

316L

adaptor only

SFCE-…G

SFCE-X-…G

including split flanges, metric bolts and o-ring

SFCE-…GM

SFCE-X-…GMX

including split flanges, UNC bolts and o-ring

SFCE-…GU

SFCE-X-…GUX

SAE-90° flange adapter BSPP-60° – forged

Catalogue page: 78

Data Sheet Product Enquiry

Ordering code:

flange only

WFG-…G

including split flanges, metric bolts and o-ring

WFG-…GM

including split flanges, UNC bolts and o-ring

WFG-…GU

SAE-45° flange adapter BSPP-60° – forged

Catalogue page: 79

Data Sheet Product Enquiry

Ordering code:

only 45° flange-adapter

WFG-…-45-G…

WFG-X-…-45-G…

including split flanges, bolts and o-ring

WFG-…-45-G...M

WFG-X-…-45-G…MX

SAE-adapter UN-ORS threaded

Catalogue page: 80

Data Sheet Product Enquiry

Ordering code:

C22

316L

adaptor only

SORS-…

SORX-…

including split flanges, metric bolts and o-ring

SORS-…M

SORX-…MX

including split flanges, UNC bolts and o-ring

SORS-…U

SORX-…UX

SAE-90° adapter UN-ORS threaded

Catalogue page: 81

Data Sheet Product Enquiry

Ordering code:

only 90° flange-adapter

WORS-…

WORX-…

including split flanges (or complete flange), metric bolts and o-ring

WORS-…M

WORX-…MX

including split flanges, unc-bolts, o-ring

WORS-…U

WORX-…UX

SAE-45° adapter UN-ORS threaded

Catalogue page: 82

Data Sheet Product Enquiry

Ordering code:

only 45° flange-adapter

WORS-…-45-…(UN)

WORX-…-45-…(UN)

including split flanges, bolts and o-ring

WORS-…-45-…(UN)M

WORX-…-45-…(UN)MX

including split flanges, unc-bolts, o-ring

WORS-…-45-…(UN)U

WORX-…-45-…(UN)UX
