Find the right product for your company. Our wide range of products consisting of over 8000 individual parts makes it possible to create customised solutions for your company. Our product portfolio includes SAE flanges (ISO 6162), SAE full flanges, screw-in flanges, external thread flanges, weld-in and weld-on flanges as well as flanges with butt-welded collars. These products can all be delivered in straight and 90° versions.

Furthermore we can deliver closing flanges, connecting flanges, flanges with measurement connections, T-connectors, reducing flanges, raised-edge flanges and SAE blocks. These as well as connections for gear pumps and square-head flange connections (ISO 6164) are available as straight and 90° versions and Cetop (standard) versions.

Get a better picture of our range of products by clicking through our extensive online catalogue below.


SAE-socket weld flange

Catalogue page: 36,37

Data Sheet Product Enquiry

Ordering code:

316L

flange only

AFS-…S

AFX-…S

including metric bolts and o-ring

AFS-…SM

AFX-…SMX

including UNC bolts and o-ring

AFS-…SU

AFX-…SUX

SAE-socket weld flange companion

Catalogue page: 38,39

Data Sheet Product Enquiry

Ordering code:

316L

flange with metric threads

GFS-…SM

GFX-…SM

flange with UNC threads

GFS-…SU

GFX-…SU

SAE-socket weld flange-coupling

Catalogue page: 40,41

Data Sheet Product Enquiry

Ordering code:

316L

flange including metric bolts and o-ring

DFS-…SM

DFX-…SMX

flange with UNC bolts and o-ring

DFS-…SU

DFX-…SUX

SAE-socket weld flange 500 PSI

Catalogue page: 42

Data Sheet Product Enquiry

Ordering code:

316L

flange only

AFC-…S

AFC-X-…S

including metric bolts and o-ring

AFC-…SM

AFC-X-…SMX

SAE-socket weld companion 500 PSI

Catalogue page: 43

Data Sheet Product Enquiry

Ordering code:

316L

flange only

GFC-…S

GFC-X-…S

SAE-socket weld flange-coupling 500 PSI

Catalogue page: 44

Data Sheet Product Enquiry

Ordering code:

316L

flange including bolts and o-ring

DFC-…SM

DFC-X… SMX

SAE-socket weld adapter

Catalogue page: 45

Data Sheet Product Enquiry

Ordering code:

adaptor only

SWA-…

including split flanges, metric bolts and o-ring

SWA-…M

including split flanges, UNC bolts and o-ring (nut and cutting ring)

SWA-…U

SAE-90° socket weld flange

Catalogue page: 46

Data Sheet Product Enquiry

Ordering code:

316L

flange only

AFS-…/90S

AFX-…/90S

including metric bolts and o-ring

AFS-…/90SM

AFX-…/90SM

including UNC bolts and o-ring

AFS-…/90SU

AFX-…/90SUX

SAE-90° socket weld flange companion

Catalogue page: 47

Data Sheet Product Enquiry

Ordering code:

316L

flange only

GFS-…/90S

GFX-…/90S
